Imported No Order No. BX-90A Customized processing No

Item No. BX-90A Brand BOOXT Model BX-90A

Classification Pneumatic right-angle screwdriver Chuck size 1/4 (inch) Idling speed 9000 (rpm)

Average air consumption 0.25m3/min Air inlet size 1/4 (inch) Recommended inner diameter of air pipe 8 (mm)

Working pressure 0.65 (Mpa) Weight 1.06 (kg) Length 210 (mm)

Scope of application Used for various screw locking operations with limited positions. Maximum torque 35Nm Tool length 210mm

Net weight of tool 1.06 (kg) Locking bolt 3-5mm Is it a source of exclusive supply for cross-border export
