Imported No Order No. BX-500A1 Customized processing No

Item No. BX-500A1 Brand BOOXT Model BX-500A1

Maximum pull stud size 4.8 (mm) Self-contained gun head size 4.8 (mm) Tension 1045 (kg)

Pull stud stroke 16 (mm) Air inlet size 1/4 (inch) Recommended inner diameter of trachea 8 (mm)

Working pressure 0.65 (Mpa) Average air consumption 0.21m3/min Height 270 (mm)

Tool height 270 (mm) Total length 320 (mm) Applicable scope Suitable for common blind rivet riveting operations

Length of tool 320 Net weight of tool 1.6 (kg) Is it a source of exclusive supply for cross-border export?
