Imported No Order No. BX-500A Customized processing No

Item No. BX-500A Brand BOOXT Model BX-500A

Maximum pull stud size 4.8 (mm) Self-contained gun head size 3.2/4.0/4.8 (mm) Pull force 958 (kg)

Pull stud stroke 18 (mm) Air inlet size 1/4 (inch) Recommended inner diameter of trachea 8 (mm)

Working pressure 0.65 (Mpa) Average air consumption 0.13m3/min Height 320 (mm)

Tool height 320 (mm) Total length 170 (mm) Applicable scope Suitable for all kinds of blind rivet fastening operations

Tool length 170mm Tool net weight 1.38 (kg) Whether it is a source of supply for cross-border export
