Imported No Order No. BX-500EX Customized processing No

Item No. BX-500EX Brand BOOXT Model BX-500EX

Place of Origin China The largest stud size 4.8 (mm) The size of the gun head is 23 (mm)

Tension 1060 (kg) Stroke of pull stud 18 (mm) Air inlet size 1/4 (inch)

Suggested inner diameter of trachea 8 (mm) Working pressure 0.65 (Mpa) Average air consumption 0.13m3/min

Height 291 (mm) Tool height 291 (mm) Total length 195 (mm)

Scope of application National standard 2.4/3.2/4.0/4.8 blind rivets of various materials. Tool net weight 1.3 (kg) Whether it is a source of special supply for cross-border export No
